Garware Technicle Fiber at a glance:-

Garsafe For Lifting Application :-
| S.W.L. (MT) | Width (mm) | Minimum Breking Strength kgs |
Color code |
| 1 | 25 | 5000 | Violet |
| 2 | 55 | 10000 | Green |
| 3 | 75 | 15000 | Yellow |
| 4 | 100 | 20000 | Grey |

Garware Neo For Lifting Application :-
| S.W.L. (MT) | Width (mm) | Minimum Breking Strength kgs |
Color code |
| 5 TON | 125 | 25000 | Red |
| 6 TON | 150 | 30000 | Brown |
| 8 TON | 200 | 40000 | Blue |
| 10 TON | 250 | 50000 | Orange |
| 12 TON | 300 | 60000 | Orange |
| 16 TON | 200 | 80000 | Blue |
| 20 TON | 250 | 100000 | Orange |
